MG60 gloss meter is currently the most small, the most portable models, the performance indicators have reached the national JJG696-2002 (specular gloss meter measurement and verification procedures) the requirements of the first-class machine.

Product use.

This product is suitable for paint, coating, ink, plastic, stone, paper, tile, enamel, stone, metal, plating layer and other products gloss measurement.

Main parameters, related standards:

Measuring range: 0~199.9Gs (gloss unit)

Stability: less than earth 0.4Gs/30Min

Graduated value 0.1 Error ± 1.2

Power supply: 2 x 7 batteries

Spot size: 10x 20mm

Measuring port size: 20 x 40mm

Use conditions: ambient temperature: 0 degrees ~ 40 degrees

Relative humidity: not more than 85%

Host size: (L) 115mm x (W) 36mm x (H) 66mm

Host weight: 240g

Host screen: LCD backlight function

Packing weight: 1000g

Packaging: Full aluminum box + EVA sponge

Outer box size: (L) 250mmx (W) 180mmx (H) 750mm

Instrument features:

◆ Ultra-compact design can be placed in the pocket, more portable, is currently the smallest volume, lightest weight gloss meter.

◆ Imported chip, ultra-low power consumption 0.5MA, normal use time up to one month, standby time of 180 days or more, about 10,000 data can be measured.

◆ Special moisture-proof process can let you rest assured in a variety of harsh environments.

◆ Instant measurement, no waiting time, stable value, no drift, easy to measure quickly.

◆ Quartz crystal standard plate: accurate, wear-resistant, gloss value is stable without change.

◆ Accurate to one decimal point, higher precision.

◆ K9 coated optical glass lens, better stability.

◆ LED white light source, lumen 6.0-7.0lm, stable luminescence, durable, no need to replace.

◆ Special customized aging bracket test bracket, to ensure data stability.

◆ Original zero calibration technology, double calibration.
